BURLINGTON A10 STRATA LEADFREE Front Radiation Protection Apron

Lightweight Protection and Ergonomic Comfort for Medical Imaging Professionals

The BURLINGTON A10 STRATA LEADFREE front radiation protection apron has been designed to provide effective protection against X-rays while significantly reducing the weight carried by the user. Thanks to its innovative lead-free multilayer technology and weight distribution system between the shoulders and hips, it helps reduce fatigue during diagnostic and interventional procedures.

Its ergonomic design adapts to a wide range of body shapes through a crossed stretch back panel, hook-and-loop shoulder strap, and adjustable elastic belt. The A10 STRATA LEADFREE apron provides excellent support while maintaining freedom of movement throughout the working day.

STRATA LEADFREE Technology: Lightweight Protection up to 120 kV

BURLINGTON STRATA LEADFREE material is based on an advanced layered protection technology that delivers excellent lead equivalency while significantly reducing the weight of the apron.

- Available lead equivalencies: 0.35 mm Pb or 0.50 mm Pb
- Tested at 50, 70, 90 and 110 kV in accordance with IEC 61331-1:2014
- Lead-free multilayer technology for significant weight reduction
- Lead equivalency determined using the inverse broad beam geometry method in accordance with IEC 61331-1:2014
- Suitable for applications using X-ray energies below 120 kV

Recommended Applications

The A10 STRATA LEADFREE front apron is particularly suitable for professionals working in:

- Interventional Radiology
- General Radiography
- Dental Imaging

Usage Limitations

Lead-free or lightweight protective garments should not be used in the following situations:

- When X-ray generator voltages are between 120 kV and 150 kV
- When using X-ray generators operating above 150 kV
- In Nuclear Medicine, regardless of the radionuclide used

Technical Features

- Ergonomic front protection design
- Adjustable elastic belt for improved weight distribution
- Crossed stretch back panel for an optimal fit
- Hook-and-loop shoulder strap
- Front buckle closure
- PVC-reinforced Velcro fastening for increased durability
- Thick padded shoulders for enhanced comfort
- Velcro replacement service available
- Standard chest pocket

Compliance and Certification

- Compliant with IEC 61331-3:2014
- H Category (Heavy Use)
- CE Certified 89/686/EEC
- Personal Protective Equipment (PPE) Category III
- Tested and approved in accordance with NF EN 61331-3:2014

BURLINGTON STRATA LEADFREE Material

STRATA LEADFREE material combines lightweight construction, effective radiation protection, and environmental responsibility.

- Rubber-based material incorporating Bismuth (Bi) and Antimony (Sb)
- 3.95 kg/m2 at 0.35 mm Pb equivalency
- 5.54 kg/m2 at 0.50 mm Pb equivalency
- 98% recyclable material
- Manufactured using a hot reformulation process

30 Colours Available

- Antibacterial outer coverings
- 4 patterned PVC colours
- 12 Polyurethane (PU) colours, plain or patterned
- 14 Nylon colours, plain or patterned
- Durable and easy-to-clean surfaces

Key Benefits of the BURLINGTON A10 STRATA LEADFREE Apron

- Lightweight lead-free technology
- Excellent protection for applications up to 120 kV
- Weight distribution between shoulders and hips
- Enhanced comfort during extended wear
- Adjustable fit for a wide range of body types
- Compliant with IEC 61331-1 and IEC 61331-3 standards
- 98% recyclable material
- 5 year warranty
