Uniray MAX Lightweight Lead Wraparound Apron

Full anti-X protection with complete overlap and optimized comfort
A full-overlap wraparound design for maximum lightweight protection

The Uniray MAX lightweight lead wraparound apron combines comprehensive radiation protection with reduced physical strain. Its full frontal overlap design effectively minimizes exposure to scattered radiation.

This enveloping model is particularly suited for environments requiring enhanced protection while improving comfort during long procedures.

Lightweight lead technology: balancing protection and comfort

The lightweight lead material is engineered with a partial lead substitution, significantly reducing the apron?s weight while maintaining high radiation protection performance.

This design provides:

a weight reduction of 20 to 30% compared to standard materials
improved comfort during prolonged wear
reduced strain on the shoulders and back

These features are especially beneficial for professionals exposed over extended periods.

High-performance anti-X protection for radiology environments

The apron delivers effective protection against ionizing radiation under typical radiology conditions.

Recommended operating range: 50 to 110 kV
- high attenuation of scattered radiation
- performance validated according to international standards

Available lead equivalences
- 0.25 mm Pb: lightweight protection
- 0.35 mm / 0.25 mm Pb: standard use
- 0.50 mm / 0.25 mm Pb: enhanced protection

Attenuation performance exceeds 99% at low energy levels and remains highly effective up to 110 kV.

Regulatory compliance in radiation protection

This model meets the requirements applicable to personal protective equipment:

- PPE Category III classification
- compliance with EU Regulation 2016/425
- CE marking 0598
- conforms to NF EN 61331-3 and IEC 61331-1 standards

These certifications ensure a level of safety aligned with healthcare industry standards.

Advanced ergonomics with integrated lumbar support

The MAX wraparound apron has been designed to improve comfort and reduce fatigue:

- flexible belt with integrated lumbar support
- optimized weight distribution between shoulders and hips
- thick shoulder padding to reduce pressure points
- design adapted to various body types

This ergonomic approach enhances working conditions during long procedures.

Fit and size adaptability

Available in multiple sizes and lengths, this model ensures a precise fit for consistent coverage.

A proper fit is essential to maintain continuous protection and avoid unshielded areas. A sizing guide is available to help select the most suitable configuration.

Coatings adapted to healthcare environments

Two finishing options are available:

Nylon offers strong wear resistance and includes antibacterial treatment.

Polyurethane stands out for its ease of cleaning, stain resistance, and user comfort.

Clinical use

The full-overlap wraparound apron is recommended for environments requiring enhanced protection against scattered radiation.

It is particularly suited for long procedures and situations where extended wear is necessary.

Customization options

Optional features include:

- internal dosimeter pocket
- chest pocket
- thyroid shield attachment
- custom embroidery or identification

Technical specifications
Type: wraparound apron with full frontal overlap
Closure: belt with lumbar support
Material: lightweight lead

Available lead equivalences:
- 0.25 mm Pb
- 0.35 mm / 0.25 mm Pb
- 0.50 mm / 0.25 mm Pb
Material weight (indicative):
- 3.1 kg/m? (0.25 mm)
- 4.5 kg/m? (0.35 mm)
- 6.2 kg/m? (0.50 mm)

Operating range: 50 to 110 kV
Sizes: XS to 3XL
Lengths: multiple options available
Coatings: nylon or polyurethane
Warranty: 2 years
