Uniray MAX Wraparound Lead Apron

Full anti-X protection with complete overlap and integrated lumbar support
A wraparound design for maximum radiation protection

The Uniray MAX wraparound lead apron is designed to provide comprehensive protection against ionizing radiation, thanks to its full frontal overlap that effectively minimizes exposure zones.

Its enveloping structure ensures optimal coverage of the torso, making it particularly suitable for environments with high levels of scattered radiation.

This model is well suited for use in radiology, operating rooms, interventional cardiology, and nuclear medicine.

High-performance radiation protection across a wide energy range

Manufactured using lead material, this apron delivers high attenuation performance across a broad spectrum of radiation energies.

Effective protection from 50 to 150 kV
Excellent shielding against scattered radiation
Suitable for high-exposure environments

Available lead equivalences
- 0.25 mm Pb: lightweight protection
- 0.35 mm / 0.25 mm Pb: standard use with optimized weight
- 0.50 mm / 0.25 mm Pb: enhanced protection for demanding environments

Measured attenuation performance exceeds 99% at lower energy levels and remains highly effective up to 150 kV.

Regulatory compliance for radiation protection PPE

The MAX wraparound apron complies with applicable standards for personal protective equipment in medical environments:

- PPE Category III
- Compliance with EU Regulation 2016/425
- CE marking 0598
- Conforms to NF EN 61331-3 and IEC 61331-1 testing standards

These certifications ensure a level of safety aligned with healthcare facility requirements.

Ergonomic design for extended procedures

This model has been developed to improve comfort during prolonged use:

- flexible belt with integrated lumbar support
- optimized weight distribution between shoulders and hips
- thick shoulder padding to reduce pressure points
- design adapted for long-duration wear

These features help reduce muscular fatigue, particularly during interventional procedures.

Precise fit and size adaptability

Available in multiple sizes and lengths, the apron adapts to different body types to ensure consistent and effective coverage.

A proper fit is essential to maintain continuous protection and avoid unshielded areas. A sizing guide is available to assist in selecting the most appropriate configuration.

Coatings suitable for clinical environments

Two finishing options are available:

- Nylon offers high resistance to wear and includes antibacterial treatment, making it suitable for regular use.

- Polyurethane provides ease of cleaning, stain resistance, and enhanced comfort, making it ideal for demanding hospital environments.

Clinical use :

The full-overlap wraparound apron is recommended for situations requiring enhanced protection against scattered radiation.

It is particularly suitable for long procedures or environments with higher exposure levels, while still allowing sufficient freedom of movement.

Customization options

Optional features include:

- internal dosimeter pocket
- chest pocket
- thyroid shield attachment
- custom embroidery or identification

Technical specifications

Type: wraparound apron with full frontal overlap
Closure: belt with lumbar support
Material: lead

Lead equivalences available:
- 0.25 mm Pb
- 0.35 mm / 0.25 mm Pb
- 0.50 mm / 0.25 mm Pb

Material weight (indicative):
- 3.4 kg/m? (0.25 mm)
- 4.8 kg/m? (0.35 mm)
- 6.8 kg/m? (0.50 mm)

- Operating range: 50 to 150 kV
- Sizes: XS to 3XL
- Lengths: multiple options available
- Coatings: nylon or polyurethane
- Warranty: 2 years
